The Pusher 3.5" MEGA Intake System with our 3.5" Passenger Side Intercooler Tube replaces all three of the pre- and post- intercooler piping and stock intake manifold with 3.5" mandrel bent tubing, dramatically increasing the flow efficiency of your charge system. Like all of our Cummins intakes, this system is capable of being run with or without the heater grid.

WHAT TO EXPECT-

• 50-200 degrees F drop in EGTs
• 0.5-1 mpg increase
• Increased throttle response
• Faster turbo spool

Intercooler Compatibility:

This product was designed to work with the factory intercoolers, and as such will work with aftermarket intercoolers that mimic the factory inlet / outlet size and locations. If you have an aftermarket intercooler that differs from that, please call for compatibility.

• Constructed of 3.5" mandrel bent tubingLaser cut 1/2" flange and 1/4" thick dipstick mounting bracket.
• Fully TIG welded with precise settings to produce optimal penetration without impacting airflow.
• Heavy duty 5-ply silicone couplers, stainless T-bolt clamps
• OEM gasket
• Port plugs
• Detailed instructions with color photos

What’s in the box?

(1) DC0307MIM | Pusher 3.5" MEGA Intake Manifold
(1) DC0307MBT | Pusher 3.5" MEGA Driver-side Charge Tube
(1) DC0307MHP | Pusher 3.5" MEGA Passenger Side Intercooler Tube
(2) PSR35-3 | 3.5 - 3" Black 5-Ply Silicone Coupler, Reducer
(1) PSS35 | 3.5" Black 5-Ply Silicone Coupler, Straight
(1) PSR35-275 | Silicone Reducer 3.5 - 2.75" Coupler 5-Ply
(5) TC_3.5 | 3.5" Stainless T-Bolt Clamp
(2) TC_3 | 3" Stainless T-Bolt Clamp
(1) TC_2.75 | 2.75" Stainless T-Bolt Clamp
(1) 59C IMS Gasket | 5.9L Cummins Intake Manifold Gasket
(1) M8 Locking Nut
(Optional) 1/8" NPT Port Plug
(5) 5/16" Washers
