Pusher 3.5" MEGA Twin Intake System 1994-1998 Dodge Cummins 12v

$699.00
SKU:
PDC9498MT_N2
Weight:
23.00 LBS
tooltip|Ports:
This product features 1/8" FNPT threaded ports for auxiliary sensors / injectors. Each port comes with a anodized aluminum plug so you can seal off ports not in use. The majority of our customers select the standard 2-port option.
tooltip|powder-coat:
All steel products must be coated prior to installation. See “Powder Coating 101” under Articles for more information.

On backorder until Aug 30th 2022

Current stock: 0
Description

Description

Get the most air to your 12v head! The Pusher 3.5" Mega Twin Intake System is the only setup on the market that delivers air to the rear cylinders and fully utilizes the factory 3.5" intercooler outlet. This allows the Pusher manifold to be fed with an additional 37.7% more air over any of the other dual ram style manifolds with stock sized 3" inlets.

To ensure our manifold gets that extra air, the Mega 3.5" Twin Intake System replaces everything from the intercooler outlet up to the new intake manifold with 3.5" components as well. Full system features are:



Intake Manifold:
  • Constructed of fully TIG welded and mandrel bent tubing with 1/2" thick flanges and a mount for the dipstick tube located lower than factory for a cleaner look.
  • All manifolds come standard with two 1/8 inch NPT ports on the back for methanol/water injection, a boost gauge, etc. More ports are available for an upcharge. Included are a matching number of anodized aluminum port plugs to seal off any ports not in use.
  • The Pusher 3.5" Mega Twin manifolds are hydro boost compatible thus fit 1994-1998 model year Ram trucks.
  • The intake manifold was designed so it can be bolted directly to the plenum cover or on top of a heater grid and the charge tube assembly will still line up.

Charge Tube Assembly:
  • 3.5" cold side charge tube with Pusher's signature large beaded ends
  • 5-ply silicone couplers rated for compound turbo system boost
  • Full stainless t-bolt clamps

Other included components:
  •  Fully CNC machined and anodized 6061-T6 aluminum plenum cover with pocketed under side to increase plenum volume. This plenum cover also retains the factory fuel filter housing mounting.
  •  All new Cummins gaskets and hardware
  • TIG welded and polished stainless injector line bracket for rear injector line cluster.
Reviews

Reviews (16)

Mike H. Feb 18th 2021

It's HUGE !!!

Overall very satisfied with fitment and quality of welds and powder coating. The only issue I have is that this intake works with stock intercooler with 3.5” outlets but I'm running a Spearco which has 3” outlets. I had to order a 3.5” - 3.0” intercooler coupler. No big deal as it was an easy fix and I should have known better when ordering. Intake looks killer and will support as much airflow as you should ever need.

Nick Butcher Jan 17th 2021

MEGA twin ram intake!!!

Thing fits like a glove and everything needed for install in the box they send. The finish and fit is great with no complaints. Great customer service as I ordered it over the phone, and last but not least 11/10 on the packing ensure that they were not a scratch dent or a worry in the world that anything will get damaged during shipping!

Additional Info

Additional Info

SKU:
PDC9498MT_N2
Weight:
23.00 LBS
tooltip|Ports:
This product features 1/8" FNPT threaded ports for auxiliary sensors / injectors. Each port comes with a anodized aluminum plug so you can seal off ports not in use. The majority of our customers select the standard 2-port option.
tooltip|powder-coat:
All steel products must be coated prior to installation. See “Powder Coating 101” under Articles for more information.
